Hazardous Material Storage Enclosures
Pro-Guard Hazardous Material Storage Enclosures are engineered to provide safe, compliant, and secure storage for hazardous materials in demanding industrial environments.
Designed for outdoor installation, these enclosures deliver reliable containment, environmental protection, and regulatory compliance for the storage of chemicals, fuels, and other hazardous substances. Built with heavy-duty construction and integrated safety features, Pro-Guard systems are trusted to perform in the harshest conditions.
From compact units to large multi-door configurations, our storage enclosures are designed to protect both personnel and the environment while supporting efficient site operations.
General Specifications
All Pro-Guard HS-Series enclosures are designed and manufactured to meet strict safety, containment, and durability requirements.
Standard Specifications:
- Heavy-duty welded steel construction for maximum strength and durability
- Integrated liquid-tight containment sump systems
- Fabricated from corrosion-protected structural and heavy-gauge steel
- Designed for outdoor installation in extreme environments
- Non-combustible construction for enhanced safety
- Chemical-resistant industrial coating systems
- Tamper-resistant, heavy-duty locking door hardware
- Configurable door layouts for operational flexibility
- Engineered for storage of drums, totes, pallets, and containers
- Designed to support regulatory compliance and environmental protection
Available Options & Customization
Pro-Guard storage enclosures can be configured to meet specific regulatory requirements, site conditions, and material storage needs.
Fire Protection & Safety
- Fire-rated enclosure configurations
- Integrated fire suppression systems
- Gas detection and monitoring systems
- Audible and visual alarm systems
Environmental Control
- Insulated enclosure packages
- HVAC systems for temperature-sensitive materials
- Ventilation systems for hazardous vapours
- Climate-controlled storage environments
Structural & Material Options
- Upgraded coatings for corrosive environments
- Stainless steel components (where required)
- Reinforced flooring and load-rated designs
- Spill containment upgrades
Access & Configuration
- Multiple door configurations and sizes
- Roll-up doors or double-door access systems
- Interior shelving and storage systems
- Drum handling and dispensing configurations
Compliance & Integration
- Site-specific compliance modifications
- Integration with facility safety systems
- Custom layouts and sizing
- Electrical packages and lighting systems
HS-Series Enclosure Size Comparison
Model | Interior Dimensions (W × L × H) | Shipping Dimensions (W × L × H) | Weight (lbs) | Doors | Sump Capacity |
HS-50 | 4’2” × 4’2” × 6’0” | 4’10” × 4’8” × 8’0” | 1,540 | 1 × 36” × 72” | 55 Gal |
HS-100 | 6’0” × 8’4” × 7’8” | 6’7” × 8’10” × 9’4” | 3,400 | 1 × 60” × 84” | 220 Gal |
HS-150 | 8’0” × 12’6” × 7’8” | 8’11” × 13’0” × 9’4” | 5,600 | 2 × 60” × 84” | 460 Gal |
HS-250 | 8’0” × 20’10” × 7’8” | 8’11” × 21’5” × 9’4” | 8,290 | 3 × 60” × 84” | 665 Gal |
HS-350 | 8’0” × 29’3” × 7’8” | 8’11” × 29’9” × 9’4” | 10,500 | 3 × 60” × 84” | 750 Gal |
HS-450 | 8’0” × 37’11” × 7’8” | 8’11” × 38’0” × 9’4” | 13,300 | 4 × 60” × 84” | 980 Gal |
Custom sizes, door configurations, and sump capacities are available to meet specific site and regulatory requirements.
Hazardous Material Compatibility
Pro-Guard HS-Series enclosures are suitable for the proper storage of TDG classes including:
- Class 2 — Compressed Gas
- Class 3 — Flammable Liquids
- Class 4 — Flammable Solids and Reactive Substances
- Class 5 — Oxidizing Substances and Organic Peroxides
- Class 6 — Toxic Substances
- Class 8 — Corrosives
- Class 9 — Miscellaneous Hazardous Materials
Applications
Pro-Guard Hazardous Storage Enclosures are ideal for:
- Oil & Gas Operations
- Mining and Resource Sites
- Chemical Storage Facilities
- Industrial Manufacturing Plants
- Environmental and Waste Management Sites
- Any location requiring compliant hazardous material storage
“Engineered for environments where containment, compliance, and safety cannot fail”
